Combining hydroforming and forging techniques, Yamaha's patented Dual Twin™ frame design provides precise handling and surrounds both rear shock and battery resulting in security, protection and a low center of gravity full suspension frame.
The NEW MTB mode offers a direct feeling assist suited for pedaling through tight corners and riding technical lines while AUTO support mode automatically switches between ECO, STD, and HIGH to provide optimal assist according to ride conditions.
|Frame||Yamaha Dual Twin Frame|
|Fork||RockShox Revelation RC Boost 160mm Tapered aluminum steerer, 1 1/8in - 1 1/2in|
|Headset||Integrated tapered headset with headset spacers|
|Rear Shock||RockShox Deluxe Select + 210mm/55mm 150mm trave|
|Rims/Wheels||Yamaha 27.5+ Alloy Tubeless tape installed Width: 46mm (OUTSIDE) 40mm (INSIDE)|
|Hubs||Anodized Centerlock brake mount Front hub 15 x 110 Boost, rear hub 12 x 148 Hyperglide freehub and Yamaha Bicycles Speed Sensor|
|Tires||Rear: CST Patrol 27.5 x 2.8in Front: CST BFT 27.5 x 2.8in Tubeless compatible rim Tubeless compatible rim strip|
|Crankset||PRAXIS ISIS 170mm|
|Chain||KMC e11 Turbo|
|Shifters||Shimano SLX 11-speed|
|Handlebars||Alloy 30mm riser bar 35.0mm diameter 780mm width|
|Tape/Grips||Locking Dual Core|
|Stem||Yamaha Alloy 4-bolt faceplate 35.0 diameter 40mm length|
|Brakes||Magura MT30 Front: 4-piston Rear: 2-piston 203mm Storm CL Rotors|
|Saddle||Yamaha Anti-slip finish with hand rail tail|
|Seat Post||Alloy 30.9mm dropper post (S/M) 125mm travel, (L) 150mm travel|
* Subject to change without notice.
